CHROMABOND® Diol (OH) – SPE Cartridges

Properties:

  • Base material silica, pore size 60 Å, particle size 45 μm, specific surface 500 m2/g
  • pH stability 2–8
  • Diol phase, carbon content 5.5%
  • Polar
  • Properties similar to SiOH

Recommended Applications:

  • Food additives from beverages
  • Alkaloids from plants
  • Antibiotics from ointments
  • Pesticides
  • Prostaglandins
SPE CHROMABOND glass columns 3mL - 500mg - Diol

CHROMABOND® Glass – 3mL – 500mg

Plastic Columns

Catalog No.DescriptionPrice (USD)
730053SPE Cartridges, Chromabond, Diol (OH), 3ml, PP, 500mg, 50/pk Buy now $209.00
730418SPE Cartridges, Chromabond, Diol (OH), 6ml, PP, 500mg 30/pk Buy now $139.00

Glass Columns

Catalog No.DescriptionPrice (USD)
730053GSPE Cartridges, Chromabond, Diol (OH), 3ml, Glass, 500mg, 50/pk Buy now $275.00
Chromabond® Polypropylene Columns

  • PP columns with PE filter elements
  • Different sizes from 1, 3, 6 up to 150 ml
  • Adsorbent weights from 20 mg to 50 g
  • Male luer tip as exit
  • Compatible with most robots (e. g. Gilson ASPEC™, Caliper AutoTrace®, …)
Chromabond® Glass Columns

  • Glass columns with chemically very inert glass fiber
  • Filter elements (nominal pore size 1 µm)
  • Two different sizes: 3 and 6 ml
  • Available with all CHROMABOND® phases
  • Excludes any influence from the column material (e. g. plasticizers, …)
Chromafix® Cartridges

  • PP cartridges with PE filter elements
  • Three different sizes with different adsorbent weights: Small (0.4 ml), Medium (0.8 ml), Large (1.8 ml)
  • Female Luer tip at the inlet, male Luer tip as exit
  • Offers an alternative way of handling using positive pressure by syringes or peristaltic pumps
  • Especially suited for convenient solid-phase extraction of small sample volumes
Chromabond® LV Columns

  • Large volume PP columns with PE filter elements
  • Three different adsorbent weights (100, 200 and 500 mg)
  • funnel-shaped reservoir with 15 ml volume
  • Especially for the clinical samples-the whole sample (e. g. urine, serum, blood) can be applied to the column in one step
  • Can be directly used in the Zymate® lab robots of Zymark
Chromabond® Multi 96- SPE in 96-Well format

  • 96-well polypropylene plates with PE filter elements
  • Cavity volume of 1.5 ml
  • Adsorbent weights from 25 to 100 mg
  • Supplied with any CHROMABOND® SPE adsorbents
  • For simultaneous preparation of 96 samples
  • Easy method transfer from CHROMABOND® columns or CHROMAFIX® cartridges to CHROMABOND® MULTI 96
  • Readily adaptable to all common automated/robotic handling systems
