Purity™ MPLC Granular Flash Cartridges
Optimize Your Scale-Up for Difficult TLC Separations
Our Purity™ MPLC Flash Cartridges have been specifically designed to optimize scale up from difficult TLC method development assays. MPLC silica gel has a tight 20-45um particle size distribution that provides higher theoretical plates for greater resolution.
When you have very low Rf values on TLC plate separations and scaling up to flash (40-63µm column) does not provide the desired separation clarity, you need the resolution power of our MPLC grades.
Choose granular for a cost-effective solution, or spherical to achieve the highest resolution and efficiencies.
Packed with Premium RF™ Silica Gel
Purity™ Flash Cartridges offer tighter particle distribution and minimal fines, keeping back pressure low.
Premium Rf Silica Gel Features:
- Proprietary packing increases speed, resolution, and loading capacity
- Small pore volume: higher bulk density
- Narrow pore size distribution: minimum small pores. Purity: 99.95% SiO2
| Purity™ Flash Cartridges MPLC Granular (20-45 µm) | |||||
|---|---|---|---|---|---|
| Cat. # | Column Size | (O.D. x L) | (I.D. x Media Bed) | Sample Load | Qty/pkg |
| CFC-52300-004-20 | 4 g | 17.2 x 113.8 | 12.4 x 56.0 | 4 mg - 0.6 g | 20 |
| CFC-52300-012-18 | 12 g | 27.8 x 134.8 | 21.4 x 73.0 | 12 mg - 1.8 g | 18 |
| CFC-52300-025-12 | 25 g | 28.0 x 184.0 | 21.4 x 123.5 | 25 mg - 3.8 g | 12 |
| CFC-52300-040-12 | 40 g | 34.2 x 184.4 | 26.7 x 117.6 | 40 mg - 6.0 g | 12 |
| CFC-52300-080-10 | 80 g | 39.0 x 257.4 | 31.2 x 185.0 | 80 mg - 12 g | 10 |
| CFC-52300-120-10 | 120 g | 48.0 x 261.5 | 38.6 x 189.0 | 120 mg - 18 g | 10 |
| CFC-52300-220-6 | 220 g | 71.4 x 223.5 | 61.4 x 139.5 | 220 mg - 33 g | 6 |
| CFC-52300-330-5 | 330 g | 71.6 x 280.2 | 61.4 x 199.2 | 330 mg - 50 g | 5 |
| Cat. # | Flow Rate | Max. Pressure | Column Volume | Column Vol. (unfilled but w/ two frits) | Cartridge Material |
| CFC-52300-004-20 | 15-30 ml/min | 300 psi (21 Bar) | 5 ml | 6.8 | PP, USP Class VI |
| CFC-52300-012-18 | 25-50 ml/min | 300 psi (21 Bar) | 19 ml | 26.2 | PP, USP Class VI |
| CFC-52300-025-12 | 25-50 ml/min | 300 psi (21 Bar) | 32 ml | 44.4 | PP, USP Class VI |
| CFC-52300-040-12 | 30-60 ml/min | 300 psi (21 Bar) | 48 ml | 65.8 | PP, USP Class VI |
| CFC-52300-080-10 | 40-80 ml/min | 300 psi (21 Bar) | 108 ml | 141.1 | PP, USP Class VI |
| CFC-52300-120-10 | 60-100 ml/min | 300 psi (21 Bar) | 160 ml | 221.1 | PP, USP Class VI |
| CFC-52300-220-6 | 80-160 ml/min | 250 psi (17 Bar) | 303 ml | 412.8 | PP, USP Class VI |
| CFC-52300-330-5 | 80-160 ml/min | 250 psi (17 Bar) | 420 ml | 589.5 | PP, USP Class VI |
